Portable industrial video borescope system

25 October 2019

The new VUCAM D is a competitively priced high performance portable industrial video borescope system. By combining new imaging technologies with field proven industrial video endoscope manufacturing, this new product offers the user excellent endoscopic image capabilities at attractive costs.

Operated by a modern touch screen and graphic user interface this system is said to set a new standard for many existing and new visual inspection technology users. The new system allows users to interchange both 4mm and 6mm video units with a single display module.

Following on from the introduction of the VUCAM XO 6mm video borescope, the latest version, the VUCAM D introduces the ability to remove the video screen module from the handset, significantly increasing the flexibility of the unit. Users can now work much more flexibly with the unit, and the interconnectivity allows users to use one video screen with a variety of insertion tubes – further reducing the investment costs when more than one borescope may be required.

Customers with the demand for a very small, light weight and portable visual inspection equipment will enjoy the proven ergonomic user interface, the touch screen operation and precise camera control. Easy to adjust, and completely removable if required, the 5,7” touch screen can be tilted to adjust for best viewing angle, and is integrated inside a light-weight robust carbon fibre housing. Connected to the insertion tube via a flexible cable, the display module can be positioned remotely for optimum viewing.

A life-time warranty high power LED light source provides excellent illumination to the scene. The camera head can be remotely articulated through 360°.

Originally designed as a 6mm dia unit with 4 way articulation, available from 2.2m to 6.6m, the range has been enhanced with a similar 4mm dia insertion tube option, again with 4 way articulation – in both cases a full set of tip adapters to enable close up and side view inspection are available.

The high quality crisp image is displayed for evaluation and captured digitally as JPEG or digital video onto SD card. Text comments can be edited without covering any of the valuable image information and recorded using a fully featured touch keyboard.

While all functions are accessible on the touch screen interface, the most frequently needed are also available as direct access buttons under the users finger tip – making inspection fast and intuitive

The system and all its accessories are stored in a slim, tailor-made transport case, with room for additional insertion tubes, spare batteries and charges and all the tip adapters required.

For more information and arrange a demonstration, please contact distributor Crimson Industrial Vision [email protected] or call +44 (0)1892 539503

 www.crimsoniv.co.uk
