Drive designer

The new version 3.0 of the Lenze Drive Solutions Designer (DSD) is capable of analysing motion profiles from simple point-to-point to complex cam profiles or dynamic reversing.Multiple axes can be evaluated on the same timescale using inverter drives, servo drives or a mix of the two.

A new energy efficiency analysis predicts the energy cost at each element of the drive - for example the inverter, the motor, the gearbox - making energy efficiency transparent. It is then easy to make changes and optimise the energy costs. It also makes it possible to accurately size the drive.
