A new Dimension
25 January 2013
DIN-rail power supply manufacturer PULS UK has extended its Dimension range, adding a CPS20 480W unit available in both 24 and 48V outputs. Features for the CPS20 power supply unit include: almost no inrush current,
DIN-rail power supply manufacturer
PULS UK has extended its
Dimension range, adding a
CPS20 480W unit
available in both 24
and 48V outputs.
Features for the CPS20 power supply unit include: almost no inrush current, helping reduce wiring and fusing costs; overload power of 120% that is available continuously below 45°C ambient making it effectively a 576W unit; and a power factor of up to 0.99, removing any apparent power issues or losses.
The unit can operate in temperatures from -25°C to 70ºC.
An ATEX approved version with conformal coating is available for use in potentially explosive areas.
As with all PULS designs efficiency is high, peaking at 94%. Despite its impressive specification the CPS20 only takes up 65mm of DIN Rail space.
Features for the CPS20 power supply unit include: almost no inrush current, helping reduce wiring and fusing costs; overload power of 120% that is available continuously below 45°C ambient making it effectively a 576W unit; and a power factor of up to 0.99, removing any apparent power issues or losses.
The unit can operate in temperatures from -25°C to 70ºC.
An ATEX approved version with conformal coating is available for use in potentially explosive areas.
As with all PULS designs efficiency is high, peaking at 94%. Despite its impressive specification the CPS20 only takes up 65mm of DIN Rail space.
