VSDs help hospital cut costs

17 September 2014

ABB authorised value provider, Inverter Drive Systems (IDS), has installed variable-speed drives (VSDs) to a number of air handling units (AHUs) in the maternity and pathology departments of Bedford Hospital, saving the hospital about £15,000 a year on air handling costs.


Bedford Hospital NHS Trust is a 370-bed acute district general hospital serving patients in North and Mid Bedfordshire. IDS approached the hospital with a proposal to investigate its motor-driven fan applications with a view to using VSDs to cut energy use.


Kevin Stephenson, estate manager for engineering, says: "We were attracted by IDS’ proposal, particularly by the low payback times of about a year they said we could achieve.”


IDS investigated the AHUs and together with the hospital, identified four AHUs as suitable candidates for retrofitting with VSDs. These were in the waiting rooms and other general areas of the neo-natal unit, maternity outpatients department, pathology ground, first and second floors. "We knew this would cause minimal disruption, as we could alter the air volumes and save energy without the need to meet the air change rates in more critical areas such as theatres,” says Stephenson.


Previously, the AHUs were used direct-on-line, with no form of control. IDS proposed retrofitting four AHUs, two in each department. The solution involved four 11kW drives and one each of 7.5, 15 and 3kW. All were three-phase, ABB HVAC drives, ACH550, with IP54 enclosures.


Before installation, IDS had predicted a speed reduction of 15% but achieved 20%. This equated to a saving in energy costs of £15,000 a year, with payback in just 11 months. As well as the energy saving, ABB says the motors will run more quietly, and suffer less wear and tear, thereby reducing the maintenance requirement.


Says Stephenson: "We were very pleased with the way the project went. IDS completed the installation on time and did what they said they would do. We have had no problems since the VSDs were installed in June 2013.”
