Spray dry role
17 April 2013
Wanner International reports that Hydra-Cell high-pressure spray drying feed pumps offer outstanding heavy-duty reliability, even in 24/7 operations.

Wanner International reports that
Hydra-Cell high-pressure spray
drying feed pumps offer outstanding
heavy-duty reliability, even in 24/7
operations.
Many feed materials are preconcentrated to form viscous liquids or slurries that can be abrasive and cause severe wear to pumps with mechanical seals. Hydra-Cell pumps have no such dynamic seals and are designed to accommodate solid particles up to 500µm in diameter.
Maintenance is minimal and easily carried out in-situ.
Compact, with a small footprint, they are designed to run-dry without incurring damage; there is further system protection should the feedstock run out and a guard against operator error. They can pump feed materials with a wide viscosity range and can handle corrosive liquids.
Being positive displacement pumps, Hydra-Cells are energy efficient. The multi-diaphragm arrangement produces a virtually pulse-less flow and the pumps do not generally require flow dampeners to achieve satisfactory atomisation.
Many feed materials are preconcentrated to form viscous liquids or slurries that can be abrasive and cause severe wear to pumps with mechanical seals. Hydra-Cell pumps have no such dynamic seals and are designed to accommodate solid particles up to 500µm in diameter.
Maintenance is minimal and easily carried out in-situ.
Compact, with a small footprint, they are designed to run-dry without incurring damage; there is further system protection should the feedstock run out and a guard against operator error. They can pump feed materials with a wide viscosity range and can handle corrosive liquids.
Being positive displacement pumps, Hydra-Cells are energy efficient. The multi-diaphragm arrangement produces a virtually pulse-less flow and the pumps do not generally require flow dampeners to achieve satisfactory atomisation.
