Intelligent cables
31 July 2018
With the introduction of the CF.Q module, igus has further developed its smart plastics offering. The module checks and evaluates cable health in real time and recommends maintenance or replacement in good time. When used in combination with isense, there are new possibilities for digitalisation and networking to make maintenance easier and more efficient.

“At the heart of every intelligent cable from igus is a complex sensor system called CF.Q,” explains Justin Leonard, the-chain director at igus. “With the module, the electrical properties can be tested, and are then compared continuously with existing chainflex test data.”
Damage caused by repeated tight bending or extreme loads can be detected reliably. In addition, predicted lifetime for cables can be determined. If the CF.Q module is installed, it informs the user by switching an NC (normally closed) contact when the pre-defined values of the electrical parameters change.
CF.Q modules are suitable for control cabinet mounting thanks to their top-hat / DIN rail housing and therefore offer flexibility in terms of integration and handling. The integration of an SD card slot make the modules suitable for data logging; a serial interface is also integrated as standard for data output. For precise insight into the measured values, igus provides a direct connection to the isense-online system.
