Malware threat: Action needed
25 January 2013
Last year's incident involving the Stuxnet malware showed that a typical automation architecture has weak points and vulnerabilities when it comes to security. This is leading many companies to question the traditional met

Last year's incident involving the Stuxnet malware showed
that a typical automation architecture has weak points and
vulnerabilities when it comes to security. This is leading
many companies to question the traditional methods used
to move information around and from plant/asset to
enterprise level. Chris Evans of Mitsubishi Electric explains
While Stuxnet was targeted at one particular plant, it has far wider implications. It has given us a wake-up call and we now need to take a fresh approach to how data is transferred and managed within all industrial control systems. The stuxnet virus changed the point of attack in the business from the seemingly very secure top end to the somewhat vulnerable middle ground. So, are we seeing the start of a revolution? Certainly, when business managers understand the implications of 'doing nothing', then it is inevitable that changes to system architectures will follow.
Stuxnet was a malicious and targeted attack, which is very difficult to protect against. The structure of the virus is now in the public domain, so mutations of Stuxnet remain a threat and it is realistic to assume that 'copycat'malware will appear in the coming years targeted at a whole range of plant and applications.
While most incidents are not as sophisticated as Stuxnet, they can still have wide ranging consequences for the business under attack. There are two fundamental factors to consider: probability and risk; and it is the analysis of these two elements which should shape any organisation's security strategy.
It is generally accepted that 'gateway PCs' found in many automation architectures, represent weak points and are vulnerable to potential malware attacks from 'the outside' and also from CDs and USB sticks.Many of these PCs are used as networked workstations and often contain the software to change and program the PLCs beneath this layer. This makes them an attractive target for anyone wishing to disrupt operations. Couple to this is the fact that many of these PCs have been poorly maintained in terms of security patches and often contain unsupported legacy versions of operating systems, raising the risk factor.
These gateway PCs were originally included to provide visualisation/control (SCADA etc), data/alarm logging and the link between the plant/asset and the enterprise systems. Initially PLC technology was not capable of delivering these requirements in an acceptable way, in other words, there was no alternative to this architecture. From an operational point of view, these requirements are still fundamental delivery points for any system architecture, but now there are alternatives.
Mitigation or change? Many IT security companies can provide products and services to mitigate against attacks on PC based systems. These solutions are fine and coupled with a good business security regime can help protect the perceived weak points in any architecture.
However it is important to understand that many of the recent cyber security offerings in the automation arena have concentrated on dealing with the problem rather than exploring how to minimise the problem happening in the first place.
New way forward Over the last few years some companies have been developing technology that challenges the traditional automation architecture, so that they can offer a robust environment while delivering the operational requirements needed. The basis of the new approach is to develop a solution which offers direct connection from the plant/asset to the enterprise systems within a rugged industrial form factor. These systems are non-PC based and are therefore not susceptible to the same operating system legacy issues that are found in a traditional PC-based system. This is complemented by the simultaneous development of intelligent solutions to provide data and alarm logging to be carried out locally at the PLC.
This technology has created the possibility of removing the gateway PC from the topology altogether: "But what about visualisation and control?" I hear you ask. A fair question and there is no crusade here to remove SCADA/visualisation from the system but there are other ways of achieving the same criteria. If data and alarm logging is happening directly at the PLC, then visualisation and control could be achieved by intelligent HMIs. Significantly, these do not have to be running a Windows operating system. If SCADA PC nodes simply must exist, then moving the critical data/alarm logging to the local PLC means that the SCADA node can be the control and visualisation element of the system, while protecting vital information in a robust PLC environment. This is a simple but effective change in architecture that offers a viable alternative to traditional methods.
Mitigation techniques can then be deployed to minimise the risk with respect to the PC-based SCADA or visualisation system. By using these techniques and technology the link between plant/asset and the enterprise can be achieved directly from the PLC level, thus minimising the risk.
Best of both worlds It appears that the best approach to this new generation of malware threat is a multi-threaded combination of a good set of mitigation techniques and best practices with a willingness to look at new architectures to achieve the operational requirements and reduce the inherent risk. Good advice from acknowledged experts, an open mind, and awareness of current and potent new issues are critical.
While Stuxnet was targeted at one particular plant, it has far wider implications. It has given us a wake-up call and we now need to take a fresh approach to how data is transferred and managed within all industrial control systems. The stuxnet virus changed the point of attack in the business from the seemingly very secure top end to the somewhat vulnerable middle ground. So, are we seeing the start of a revolution? Certainly, when business managers understand the implications of 'doing nothing', then it is inevitable that changes to system architectures will follow.
Stuxnet was a malicious and targeted attack, which is very difficult to protect against. The structure of the virus is now in the public domain, so mutations of Stuxnet remain a threat and it is realistic to assume that 'copycat'malware will appear in the coming years targeted at a whole range of plant and applications.
While most incidents are not as sophisticated as Stuxnet, they can still have wide ranging consequences for the business under attack. There are two fundamental factors to consider: probability and risk; and it is the analysis of these two elements which should shape any organisation's security strategy.
It is generally accepted that 'gateway PCs' found in many automation architectures, represent weak points and are vulnerable to potential malware attacks from 'the outside' and also from CDs and USB sticks.Many of these PCs are used as networked workstations and often contain the software to change and program the PLCs beneath this layer. This makes them an attractive target for anyone wishing to disrupt operations. Couple to this is the fact that many of these PCs have been poorly maintained in terms of security patches and often contain unsupported legacy versions of operating systems, raising the risk factor.
These gateway PCs were originally included to provide visualisation/control (SCADA etc), data/alarm logging and the link between the plant/asset and the enterprise systems. Initially PLC technology was not capable of delivering these requirements in an acceptable way, in other words, there was no alternative to this architecture. From an operational point of view, these requirements are still fundamental delivery points for any system architecture, but now there are alternatives.
Mitigation or change? Many IT security companies can provide products and services to mitigate against attacks on PC based systems. These solutions are fine and coupled with a good business security regime can help protect the perceived weak points in any architecture.
However it is important to understand that many of the recent cyber security offerings in the automation arena have concentrated on dealing with the problem rather than exploring how to minimise the problem happening in the first place.
New way forward Over the last few years some companies have been developing technology that challenges the traditional automation architecture, so that they can offer a robust environment while delivering the operational requirements needed. The basis of the new approach is to develop a solution which offers direct connection from the plant/asset to the enterprise systems within a rugged industrial form factor. These systems are non-PC based and are therefore not susceptible to the same operating system legacy issues that are found in a traditional PC-based system. This is complemented by the simultaneous development of intelligent solutions to provide data and alarm logging to be carried out locally at the PLC.
This technology has created the possibility of removing the gateway PC from the topology altogether: "But what about visualisation and control?" I hear you ask. A fair question and there is no crusade here to remove SCADA/visualisation from the system but there are other ways of achieving the same criteria. If data and alarm logging is happening directly at the PLC, then visualisation and control could be achieved by intelligent HMIs. Significantly, these do not have to be running a Windows operating system. If SCADA PC nodes simply must exist, then moving the critical data/alarm logging to the local PLC means that the SCADA node can be the control and visualisation element of the system, while protecting vital information in a robust PLC environment. This is a simple but effective change in architecture that offers a viable alternative to traditional methods.
Mitigation techniques can then be deployed to minimise the risk with respect to the PC-based SCADA or visualisation system. By using these techniques and technology the link between plant/asset and the enterprise can be achieved directly from the PLC level, thus minimising the risk.
Best of both worlds It appears that the best approach to this new generation of malware threat is a multi-threaded combination of a good set of mitigation techniques and best practices with a willingness to look at new architectures to achieve the operational requirements and reduce the inherent risk. Good advice from acknowledged experts, an open mind, and awareness of current and potent new issues are critical.
