Filter housings extended

These products complement the existing range of competitively-priced aluminium filter housing with connection sizes now covering from 1/4” up to 4” BSP, offering a throughput flow range from 20 up to 1700 cfm. For larger flow rate patterns, a range of flanged steel filter housings can also be supplied for flow rates up to 15,000 cfm.

The latest 1/4” BSP additions, designated as part numbers HF20 and HF22, feature a robust die cast construction in high grade aluminium. They also incorporate an overall Alu-Chrome treatment which provides corrosion protection against aggressive condensates. The outer surface is also subject to a tough baked-on epoxy coating in RAL 5015 Compressed Air Blue. For OEM requirements, this final coating can also be undertaken in any colour.

The HF20 and HF22 products are also fitted with a stainless steel condensate drain to ensure improved condensate removal.
